EPOS Command HME 130

The EPOS COMMAND HME 130 is a rugged passive aviation headset designed for pilots who require effective passive noise attenuation, clear voice transmission and reliable operation without batteries or active electronics. Its closed, over-ear design makes it particularly suitable for General Aviation and demanding high-noise cockpit environments.

The HME 130 is part of the professional EPOS COMMAND series and combines rugged construction with advanced speaker and microphone technology. Particular emphasis has been placed on clear speech transmission and reproduction as well as effective isolation from distracting ambient noise.

The closed, circumaural ear cups provide passive noise attenuation of up to 40 dB at 1 kHz. This effectively reduces distracting cockpit and ambient noise without requiring active noise cancellation or an additional power supply.

Especially in noisy cockpit environments, the high level of passive noise attenuation helps improve the intelligibility of radio and intercom communications while reducing acoustic fatigue during flight.

For clear and reliable voice transmission, the COMMAND HME 130 features a noise-compensated bidirectional electret microphone. In combination with EPOS Voice™ technology, the microphone system is designed to provide precise speech pickup and excellent intelligibility even in environments with high background noise.

The flexible 21 cm microphone boom allows precise positioning of the microphone directly in front of the mouth. The boom can be swivelled, allowing the microphone to be worn on either the left or right side.

The large, closed ear cups are equipped with soft leatherette ear pads. The circumaural design completely surrounds the ears, providing a consistent seal and contributing significantly to the headset's high passive noise attenuation.

The adjustable, padded headband allows the headset to be individually adapted to the user and, together with the soft ear pads, provides a secure and comfortable fit.

The high-quality dynamic speakers feature a frequency response of 60 to 17,000 Hz and an impedance of 300 Ohms. This provides clear and precise reproduction of speech and audio signals.

The integrated volume control on the ear cup allows the listening level to be adjusted quickly and easily.

The headset operates entirely passively and requires no batteries or separate power supply, making it simple and reliable for everyday aviation use.

This version of the COMMAND HME 130 features an approximately 1.5 m connection cable with standard GA dual plugs. The headphones connect via a 6.35 mm jack plug, while the microphone uses a 5.25 mm jack plug.

EPOS provides a 5-year manufacturer's warranty for the COMMAND HME 130.

Features:

Passive aviation headset

Suitable for General Aviation

Designed for demanding high-noise cockpit environments

Closed Around-the-Ear / Circumaural design

Up to 40 dB passive noise attenuation at 1 kHz

No batteries or external power supply required

EPOS Voice™ technology

Noise-compensated electret microphone

Bidirectional microphone characteristic

Clear speech pickup and transmission

Flexible microphone boom

Microphone boom length approx. 21 cm

Microphone can be worn on the left or right side

Dynamic speakers

Closed circumaural ear cups

Soft leatherette ear pads

Adjustable, padded headband

Volume control on the headset

Approx. 1.5 m connection cable

Standard GA dual plugs

5-year manufacturer's warranty

Technical Specifications:

Model: EPOS COMMAND HME 130

EPOS Article No.: 1001342

Application: General Aviation

Noise reduction: Passive

Passive noise attenuation: Up to 40 dB at 1 kHz

Design: Closed / Circumaural / Around-the-Ear

Speaker size: 36 mm

Headphone frequency response: 60 – 17,000 Hz

Headphone impedance: 300 Ohms

Sensitivity: 96 dB at 1 kHz / 1 mW

Sensitivity at 1 V: 104 dB at 1 kHz

Maximum sound pressure level: 120 dB

Total harmonic distortion: < 0.5% at 1 kHz

Microphone: Electret microphone

Microphone characteristic: Noise-compensated / Bidirectional

Microphone frequency response: 160 – 10,000 Hz

Microphone sensitivity: 40 mV/Pa ±3 dB at 1 kHz

Microphone supply voltage: 8 – 16 V DC

Recommended load resistance: 220 Ohms

Microphone boom length: approx. 21 cm

Ear pads: Leatherette

Contact pressure: approx. 900 g ±10%

Connector: Standard GA dual plugs

Microphone connector: 5.25 mm jack plug

Headphone connector: 6.35 mm jack plug

Cable length: approx. 1.5 m

Headset dimensions: approx. 95 × 160 × 190 mm

Ear cup dimensions: approx. 115 × 85 mm

Operating temperature: -15 °C to +55 °C

Storage temperature: -55 °C to +70 °C

Manufacturer's warranty: 5 years

Scope of Delivery:

EPOS COMMAND HME 130 Aviation Headset

Protective carrying bag

Microphone windscreen

Cable clip

Quick guide

Safety guide

The EPOS COMMAND HME 130 is an excellent choice for pilots looking for a rugged passive aviation headset with high noise attenuation. The combination of up to 40 dB passive noise attenuation at 1 kHz, EPOS Voice™ technology, a noise-compensated electret microphone, closed over-ear design and standard GA dual plugs provides a reliable solution for General Aviation – without batteries or active noise cancellation.
